LbatteryNGER
BATTERY LIFE

Introducing VPG 5kΩ load cells

Extend portable scales' operation time
5K load cell solution - VPG Force Sensors innovation
2 YEAR WARRANTY

For your customers, it's freedom like never before

Energize portable devices to work longer

With the innovative 5kΩ load cells from VPG Force Sensors, your portable scales can operate longer between charges. Your customers can go further and achieve more with their battery-powered weighing devices while benefiting from industry-leading measurement accuracy and reliability.

The lowest power consumption in their class

Standard load cells typically feature a 350 Ω impedance bridge or, in some cases, a bridge with up to 1000 Ω. Going far beyond the norm, our 5kΩ load cells feature a 5000 Ω impedance bridge. This ultra-high impedance drastically reduces load cell current consumption – by as much as 70% – and thus extends the battery life of the scales.

5kΩ products

Our 5kΩ line currently includes the following off-the-shelf models:

Model 1022 5kΩ

Single-Point Aluminum Load Cell

Model 3410 5kΩ

Shear Beam Load Cell

Model 1022 – 5k
NTEP
Item Description 1 Description 2
01022-005K-D5-05F 1022-5kg-5000S-85 00M5-AL-Pott-IP66-STD
01022-007K-D5-03F 1022-7kg-5000S-85 00M5-AL-Pott-IP66-STD
01022-010K-D5-04F 1022-10kg-5000S-85 00M5-AL-Pott-IP66-STD
01022-015K-D5-05F 1022-15kg-5000S-85 00M5-AL-Pott-IP66-STD
01022-020K-D5-05F 1022-20kg-5000S-85 00M5-AL-Pott-IP66-STD
01022-030K-D5-03F 1022-30kg-5000S-85 00M5-AL-Pott-IP66-STD
Non-OIML
Item Description 1 Description 2
01022-005K-G0-07X 1022-5kg-NA C3-30 003M-AL-Pott-IP66-STD
01022-007K-G0-01X 1022-7kg-NA C3-85 00M5-AL-Pott-IP66-STD
01022-010K-G0-00X 1022-10kg-NA C3-85 00M5-AL-Pott-IP66-STD
01022-015K-G0-00X 1022-15kg-NA C3-85 00M5-AL-Pott-IP66-STD
01022-020K-G0-01X 1022-20kg-NA C3-85 00M5-AL-Pott-IP66-STD
01022-030K-G0-00X 1022-30kg-NA C3-85 00M5-AL-Pott-IP66-STD
*FM approved products are available upon request
Model 3410 – 5k
Non-OIML
Item Description 1 Description 2
03410-001T-G0-00X 3410-1ton-NA C3-30 00M5-AL-Pott-IP66-STD
03410-002T-G0-00X 3410-2ton-NA C3-30 005M-AS-C&Pt-IP67-STD
03410-500K-G0-00X 3410-500kg-NA C3-30 05M2-AS-C&Pt-IP67-STD
03410-680K-G0-00X 3410-680kg-NA C3-1C 03M2-AS-C&Pt-IP67-STD
*FM approved products are available upon request

Interchangeable

VPG 5kΩ load cells have the same fit and form as comparable standard load cells, with the only functional difference being the higher impedance.
They are interchangeable with equivalent load cells, enabling drop-in replacement in most existing product designs.

Custom solutions

Our 5kΩ solution is also available with customized load cell solutions.
Talk to us about your requirements.

Make VPG 5kΩ your advantage

Empower portable devices

  • Reduces current consumption
  • Extends device operation time
  • Enables higher utilization

Extraordinary impedance, ordinary size

  • 5000 Ohm packed into standard load cell geometries
  • Ideal for any battery-powered weighing device
  • Interchangeable with equivalent standard load cells

High quality

  • VPG Force Sensors’ renowned precision and reliability
  • 24 month warranty

5kΩ where you need it

  • Available with custom load cell solutions

Certifications

OIML logo
NTEP logo
ATEX logo
IECEx logo
UKCA logo
FM APPROVED logo
* OIML Approval pending

Key applications

The VPG 5kΩ solution is ideal for weighing applications in any battery-powered device.

Portable infant scales

Portable hospital scales

Bathroom scales

Portable legal for trade grocery scales

Kitchen scales

E-bike power meters

Manual forklifts
